Cambium Networks V5000 cnWave 60GHz Distribution Node

ST02524
Cambium Networks cnWave V5000>span class=""> is a high-performance 60 GHz Distribution Node designed to deliver fibre-like wireless gigabit...
Full description
83,559.00
+
83,559.00



Cambium Networks cnWave V5000>span class=""> is a high-performance 60 GHz Distribution Node designed to deliver fibre-like wireless gigabit connectivity for edge access and high-capacity backhaul applications. Built on the 802.11ay standard and certified for Facebook Terragraph, this node is engineered for high-density deployment scenarios in urban and suburban environments.

>span class="">. With channel bonding, it can deliver an impressive aggregate throughput of up to 15.2 Gbps while maintaining ultra-low latency of under 1 ms, suitable for real-time applications.

Product Type60 GHz Distribution Node (DN) for fixed wireless networks
Frequency Range57 to 66 GHz in a single SKU
Technology802.11ay (Certified for Facebook Terragraph)
Max ThroughputUp to 15.2 Gbps (7.6 Gbps UL + 7.6 Gbps DL) with channel bonding
Latency< 1 ms
CoverageDual sector, up to 280 degrees with beamforming
AntennaIntegrated 22.5 dBi with 12° beam width
Mode of OperationPTP, PMP, and Mesh configurations
Ethernet Interfaces1x 10G BaseT (PoE In), 1x 1G BaseT (PoE Out), 1x SFP+
Security128-bit AES Encryption
ManagementcnMaestro (Cloud or On-Premise)
Operating Temperature-40°C to +60°C (-40°F to +140°F)
Dimensions (W x H x D)185 x 280 x 102 mm
Weight4 kg
